Customized 104inch High Definition 3D Teaching Conference All-in-One Machine
Place of Origin:Henan, China
Brand Name:SHENGLONG
Model Number:SMRP-3D1042K/VGGY
Minimum Order Quantity:1 set
Price:$21,549 / set
Product Details
Application:
Indoor
Aspect Ratio:
Customize
Screen Type:
Led
Warranty:
1 Year, 3 Years, 5 Year
Brightness:
500 Cd
Color:
Full Color;RGB
Display Function:
Graphics, Animation, Text
Function:
Custom Products
Installation Type:
Wall, Wall Hanging, Hoisting, Column, Etc
Lifespan (Hours):
100000
Media Available:
Datasheet, Photo, EDA/CAD Models
Operating Temperature:
-10℃~+45℃
Operation System:
Android, Other
Pixels:
1.2 Mm
Remote Device Management:
Split-screen Remote:
Resolution:
1920*1080
Response Time:
Quick Reaction
Specification:
3D Display Function
Supplier Type:
OEM, ODM, Original Manufacturer
Usage Environment:
Indoor
Use:
Conference
Type:
Polarized 3D Product All-in-One Machine
Cabinet Size:
2880mm*1620mm
Display Mode:
3D Interlaced Row/column Display
Compatibility Mode:
Left-right Format/Top-bottom Format
Contrast:
≥10000:1
Image Resolution:
≥99%
Maximum Power Consumption:
800W/㎡
Picture Deconvergence:
NO
Image Crosstalk Rate:
<1%
Product Description
Product Specifications
| Type |
Polarized 3D Product All-in-One Series
|
|||
| Model Number | SMRP-3D2084K/VGGY | SMRP-3D1562K/VGGY | SMRP-3D1302K/VGGY |
SMRP-
3D1042K/VGGY
|
| Pixel Pitch | 1.2mm | 1.8mm | 1.5mm | 1.2mm |
| Resolution | 3840*2160 | 1920*1080 | 1920*1080 | 1920*1080 |
| Cabinet size | 4608mm×2592mm | 3456mm×1944mm | 2880mm×1620mm | 2304mm×1296mm |
| Technology |
Optical circular polarization
|
|||
| Display mode |
3D interlaced row/column display
|
|||
| Compatibility mode |
2D/3D compatible
|
|||
| 3D format |
Left-right format/Top-bottom format
|
|||
| 2D/3D Resolution |
3D model loses half
|
|||
| Video compatible |
Supports 2D and 3D video playback, can switch with one click
|
|||
| anti-reflective |
Reflectance is less than 2%
|
|||
| Image adaptive |
Support
|
|||
| Contrast |
≥10000:1
|
|||
| Picture deconvergence |
NO
|
|||
| Image resolution |
≥99%
|
|||
| Image crosstalk rate |
＜1%
|
|||
| Unit net weight |
≤7KG
|
|||
| Maintenance method |
front maintenance/Post-maintenance
|
|||
| Brightness |
0~500CD/㎡Adjustable
|
|||
| Maximum power consumption |
800W/㎡
|
|||
| Average power consumption |
300W/㎡
|
|||
| Power supply requirements |
AC100~240V(50-60Hz)
|
|||
| Frame rate conversion |
60Hz
|
|||
| refresh rate |
3840Hz
|
|||
| Typical lifespan |
100000h
|
|||
| Working temperature range |
-10℃~+45℃
|
|||
| Storage temperature range |
-20℃~+65℃
|
|||
| Working humidity range |
10%~90%,No condensation
|
|||
| Storage humidity range |
10%~90%,No condensation
|
|||
|
Remark：The parameter differences caused by product upgrade and replacement shall be subject to the final manufacturer's product specification.。
|
||||
Frequently Asked Questions
Q1: Can you customize the LED products according to our requirements?
A1: Of course! We offer comprehensive customized services for LED screens. Our engineering team will provide you with a tailor-made solution within 24 hours.
Q2: Do your LED products have certifications for international markets (such as those from the EU and the US)?
A3: We have passed comprehensive certification and can meet global import standards, including: CE/RoHS; FCC ; ISO9001
Q3: What kind of after-sales support will you provide?
A4: We offer comprehensive after-sales support for our products:
Warranty period: 2-year warranty for the entire screen (the LED module is the core component, with a 3-year warranty);
Spares: Each order will come with an additional 1-2% of spare LED modules/components for emergency replacement;
Q4: Can I place an order for a sample first to test the quality of the LED screen?
A5: Yes, sample orders are welcome! We can provide a small standard LED screen, or customize a sample according to your requirements to test. If your batch order reaches 100 square meters or more, the cost can be refunded.
