LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application

Place of Origin:Henan, China
Brand Name:SHENGLONG
Model Number:SMRP-3D1302K/VGGY
Minimum Order Quantity:1 piece
Price:$5,998-84,000 / piece
Product Details
Application: Indoor
Aspect Ratio: 16:9/4:3/1:1
Screen Type: Led
Warranty: 1 Year, 3 Years, 5 Year
Brightness: 0-800cd/㎡ Adjustable
Color: RGB
Color Depth: Supports Adjustable 0-24 Bits
Content Management System: Support
Contrast Ratio: 250000:1
Dimensions: Customize
Display Function: LED
Function: 2D/3D
Installation Type: Fixed Installation, Grounding Installation
Ip Rating: IP54
Lifespan (Hours): 100000 Hours
Mounting Type: Wall Mounted, Embedded, Suspended, And Vertical In
Operating Temperature: -20℃~60℃
Operation System: Customize
Panel Brand: Customize
Pixel Density: 694444/㎡ 444444/㎡ 308640/㎡
Pixel Pitch: P1.2 P1.5 P1.8
Remote Device Management: Support
Resolution: 1920*1080 3840*2160
Response Time: 6.2ms
Specification: 3D Display
Supplier Type: OEM, ODM, Original Manufacturer
Usage Environment: Indoor
Use: Indoor
View Angle（H/V）: "Horizontal Viewing Angle ≥ 160 ° Vertical Viewing Angle ≥ 160 °"
Voltage: 110/220V
Luminance: Customize
Provide Test Report: Yes
Shape: Customize
Certificate: CE/CCC/FCC/ROHS/ISO9001
Product Name: Conference All-in-one Machine
Installation: Custom Made
Product Description
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 0
System Configuration
Operating system
Android 11.0, Windows 10 smart dual system
Android motherboard configuration
Multi-core processor + 8G memory + 64G storage
OPS host configuration
Multi-core processor + 8G memory + 128G storage (upgradeable)
Intelligent interaction
Wireless screen projection
Support screen projection, Android system projection (need to download software), iOS system projection
Screen projection method
Software/hardware projection
Screen projection window
Support 2, 4, 6, 9 split screens
Writing whiteboard
Support full screen erasing, brush settings, exporting pictures, exporting PDFs, scanning the code to obtain whiteboard content
Touch function
Support up to 20 touch points
Annotation function
Support annotation saving, scanning code
Android Functional Interface
Video interface
2-channel HDM11.4, 1-channel TYPE-C
Audio interface
1-channel SPDIF
USB
1-channel USB 3.0, 3-channel USB2.0
Network interface
Ethernet, WiFi
Control interface
1-channel RS232 (RJ-45)
OPS Function Interface
Video interface (OUT)
1-channel HDM11.4 (output to monitor)
Audio interface
1-channel LINE-OUT/MIC-IN
USB
2-channel USB3.0
Network interface
Ethernet, WiFi
Audio equipment
Audio
Built-in 2 speakers (1008w*2), external speakers can be connected
Video conference
Conference platform
Supports mainstream platforms such as Huawei Welink, Xiaoyu Yilian, Tencent Conference, etc.






Optional Configuration





Camera
Fixed pan/tilt, 1080P, suitable for 30-60m², 5x lossless zoom/2x digital zoom, with sound pickup, horizontal/vertical rotation,
infrared remote control, external power supply required
Fixed pan/tilt, 4K (3840×2160) ultra-high definition, suitable for 30-100m², 12x optical zoom, auto focus technology, AI humanoid
tracking, multiple video output interfaces, support remote control, 340° rotation, external power supply required

Microphone
Support 360° omnidirectional microphone access, wireless digital omnidirectional microphone: built-in 1800mAh battery, 8 hours of
battery life, 2.4G wireless transmission adapter, transmission distance 10 meters, sound pickup radius 5 meters
Wireless screen projector
Support HDM11.4, HDMI2.0, USB2.0
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 2
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 4
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 6
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 8
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 10
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 12
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 14
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 16
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 18
Screen size (inches)
110
110
138
138
165
165
165
Screen size (W×H)
 (m)
2.4384
×
1.3716
2.4384
×
1.3716
3.048
×
1.7145
3.048
×
1.7145
3.6576
×
2.0574
3.6576
×
2.0574
3.6576
×
2.0574
Screen resolution (pixels)
1920
×
1080
3840
×
2160
19200
×
1080
3840
×
2160
1920
×
1080
3840
×
2160
7680
×
4320
Complete device size (WxH}
(m)
2.4604
×
1,5026
2.4604
×
1,5026
3.07
×
1.8455
3.07
×
1.8455
3.6796
×
2.1884
3.6796
×
2.1884
3.6796
×
2.1884
Working brightness (cd/m²)
0-800 adjustable
Peak brightness (cd/m)
21200
Brightness correction
Support
Chroma correction
Support
Driving mode
Constant current PWM pivot
Grayscale level
16 bit
Box connection method
Hard connection
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 20
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 22
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 24
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 26
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 28
Company Profile
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 30
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 32
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 34
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 36
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 38
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 40
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 42
Zhengzhou Shenglong Information Technology Co., Ltd. (stock code: 831361), founded in 1998, is one of the earliest high-tech enterprises in the world engaged in the design, production and installation of LED display systems. The company adheres to the concept of creative R&D design and is committed to the research and development of technical products in the field of special displays. It is an advocate and pioneer of new display technologies in China.

Zhengzhou Shenglong Information Technology Co., Ltd. has a technical team with doctoral supervisors, master supervisors and senior engineers as the core. The technical staff have decades of R&D experience. Many of them have participated in the compilation of the textbook "Optoelectronic Display Technology and Application" for Chinese universities. Team members have participated in the
construction of major projects such as the Chinese government's countdown board for the return of Hong Kong to the world-renowned Tiananmen Square, the largest screen in Asia, and the Sydney Olympics.
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 44
Zhengzhou Shenglong Information Technology Co., Ltd. has successively passed ISO quality system, national standard quality system, information security management system, intellectual property management system, as well as US FCC certification, EU CE, EU RoHS and other certifications; It has more than 70 patents and software copyrights, and has established the "Henan Intelligent Control and Aviation Information Technology Engineering Technology Research Center" and "Zhengzhou Information Security Protection Display System Engineering Technology Research Center" scientific research platforms recognized by the government; Won nearly 100 qualifications and honors such as "Specialized and New", "Top 50 Electronic Information Enterprises", "National 100 Quality and Integrity Enterprises", "National VR Industry Quality Leading Enterprise", "Science and Technology Innovation Award", and "Excellent Technology Award"
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 46
In 2003, Shenglong Co., Ltd. successfully developed a sub-outdoor display system, which reduced the cost of conventional outdoor display screens by more than half and quickly became popular throughout the country; In 2010, the first domestic macro rear projection based on LED light source was successfully developed and patented, effectively solving the moiré problem caused by camera shooting of studio and stage background screens, and creating a new display technology field; In 2013, a series of three-dimensional display products based on LED light source were successfully developed and patented, solving the problem of lack of 3D large-screen display equipment in domestic 3D teaching. It was listed as a recommended product for 3D classroom solutions in the "3D Education Research Blue Book" of the Ministry of Education, and has been widely used in many primary and secondary schools, colleges and universities, and research institutes across the country; Based on the needs of confidentiality system customers, Shenglong Co., Ltd. took the lead in developing the "Information Security Display System" in 2020, filling the gap in the field of information security display in China.
Project Construction
Professional construction team, On-site installation service.
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 48
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 50
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 52
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 54
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 56
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 58
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 60
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 62
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 64
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 66
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 68
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 70
Customer Photos
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 72
Exhibition
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 74
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 76
LED Touch All-in-One Conference Teaching Machine Computer Integrated with Indoor Application 78
Product Summary

System ConfigurationOperating system Android 11.0, Windows 10 smart dual systemAndroid motherboard configurationMulti-core processor + 8G memory + 64G storageOPS host configurationMulti-core processor + 8G memory + 128G storage (upgradeable)Intelligent interactionWireless screen projectionSupport ...
