Factory Customized Commerical Poster LED Video Wall Screen Foldable LED Poster Display Screen
Place of Origin:Henan, China
Brand Name:shenglong
Model Number:SLED-G 64192 18/S
Minimum Order Quantity:1 unit
Price:$1,113 / unit
Product Details
Application:
Indoor, Outdoor
Aspect Ratio:
1:3
Screen Type:
Customized
Warranty:
5 Year, 1 Year, 3 Years
Brightness:
0-800cd
Color:
RGB
Color Depth:
Supports Adjustable 0-24 Bits
Content Management System:
Customized
Contrast Ratio:
≥5000:1
Control Method:
Synchronous Control
Dimensions:
640mm * 1920mm * 60mm
Display Function:
Flat Display
Function:
SDK
Installation Type:
No Installation Required
Ip Rating:
IP35
Lifespan (Hours):
100000
Media Available:
Datasheet, Photo, EDA/CAD Models
Mounting Type:
Plug In And Use
Operating Temperature:
-20℃~60℃
Operation System:
Backlight
Pixel Density:
160000/㎡
Pixels:
1.86mm
RAM:
Customized
Remote Device Management:
Support
Resolution:
344*1032
Size:
50
Specification:
Digital Poster, Touch Screen, Kiosk, LED Cabinet
Storage:
Customized
Supplier Type:
Original Manufacturer, ODM, OEM
Touch Screen:
Customized
Touch Type:
Customized
Usage Environment:
10% -90% Relative Humidity, No Condensation
Use:
LED Video Wall
View Angle（H/V）:
140°/140°
Voltage:
100V-240V
Product Name:
LED Poster Screen
Module Pixel:
172*86
Led Lamp:
SMD1515
Cabinet Pixel:
344*1032
Module Size (Mm):
320*160*mm
Cabinet Size(Mm):
640*1920mm
Max Power(W/m2):
440w/㎡
Maintenance:
Front
Power Input:
100-240v AC 50-60Hz
Install Method:
Stack
Product Description
Specification
|
Product Model |
SLED-G 64192 18/S |
SLED-G 64192 20/S |
SLED-G 64192 25/S |
|
Pixel Pitch |
1.86mm |
2mm |
2.5mm |
|
Led Lamp |
SMD1515 |
SMD1515 |
SMD2121 |
|
Module Pixel |
172*86 |
160*80 |
128*64 |
|
Cabinet Pixel |
344*1032 |
320*960 |
256*768 |
|
Module Size (mm) |
320*160*mm |
||
|
Cabinet Size(mm) |
640*1920mm |
||
|
Brightness(nits)/Scan |
800-1000(43s) |
800-1000(40s) |
800-1000(32s) |
|
Max Power(w/m2) |
440w/㎡ |
||
|
Install Method |
Stack |
||
|
Maintenance |
Front |
||
|
Power Input |
100-240v AC 50-60Hz |
||
|
Working Humidity |
-20~ +45 |
||
|
Refresh Rate(Hz) |
3,840Hz |
||
|
IP Rating |
IP35 |
||
|
Signal Input |
S-video/VGA/DVI/HDMI/SDI |
||
Q1: Can you customize the LED products according to our requirements?
A1: Of course! We offer comprehensive customized services for LED screens.Our engineering team will provide you with a tailor-made solution within 24 hours.
Q2: Do your LED products have certifications for international markets (such as those from the EU and the US)?
A2: We have passed comprehensive certification and can meet global import standards, including: CE/RoHS; FCC ; ISO9001
Q3: What kind of after-sales support will you provide?
A3: We offer comprehensive after-sales support for our products:
Warranty period: 2-year warranty for the entire screen (the LED module is the core component, with a 3-year warranty);Spares: Each order will come with an additional 1-2% of spare LED modules/components for emergency replacement;
Q4: Can I place an order for a sample first to test the quality of the LED screen?
A4: Yes, sample orders are welcome! We can provide a small standard LED screen, or customize a sample according to your requirements to test. If your batch order reaches 100 square meters or more, the cost can be refunded.
