Concert Event Stage Video Background Indoor 3mm Pixel LED Display Screen
Place of Origin:China
Minimum Order Quantity:1 piece
Price:$515-982 / piece
Product Details
Application:
Indoor
Pixels:
3 Mm, 3.91
Type:
LED
Warranty:
3 Years, 1 Year, 5 Year
Brightness:
800
Content Management System:
No
Contrast Ratio:
6000:1
Media Available:
Datasheet, EDA/CAD Models, Photo
Pixel Density:
65536
Refresh Rate:
3840
Remote Device Management:
No
Sunlight Readable:
No
Product Description




Parameter | SLED-ZN 5050 26/S | SLED-ZN 5050 26/S | SLED-ZN 5050 26/S | |||
Module Parameter | Pixel Pitch(mm) | 2.6 | 2.97 | 3.91 | ||
LED Type | SMD1515 | SMD1515 | SMD2020 | |||
Module Resolution(W*H) | 96*96 | 84*84 | 64*64 | |||
Pixel Density(point/㎡) | 147456 | 112896 | 65536 | |||
Cabinet Parameter | Module Composition(W*H) | 2*2=4Pcs | ||||
Cabinet Resolution(W*H) | 192*192 | 168*168 | 128*128 | |||
Cabinet Size(W*H*D,mm) | 500*500*76 | |||||
Weight(kg/Cabinet) | ≤7.5 | |||||
Maintenance Method | Front Maintenance | |||||
Cabinet Flatness( mm) | ≤0.3 | |||||
Optical Parameter | White Balance(nits) | ≥800 | ||||
Color Temperature(K) | 3000~15000K Adjustable | |||||
Horizontal Viewing Angle(°) | ≥ 160 | |||||
Vertical Viewing Angle(°) | ≥ 140 | |||||
Contrast Ratio | ≥6000:1 | |||||
Color Uniformity | ±0.003Cx, Cy within | |||||
Visual Distance(m) (=PITCH*1) | ≥3 | ≥3 | ≥4 | |||
Electrical | Average Power Consumption(W/㎡) | ≤212 | ≤207 | ≤ 180 | ||
Parameter | Max Power Consumption(W/㎡) | ≤636 | ≤620 | ≤ 540 | ||
Input Voltage(V) | 100~240 | 100~240 | 100~240 | |||
Module Connection | Flexible Connection | |||||
Processing Performance | Scan | 1/24S | 1/21S | 1/16S | ||
Refresh Rate(Hz) | ≥3840 | |||||
Driving Mode | Common Positive Constant Current PWM Drive | |||||
Gray Scale (bit) | ≥ 14 | |||||
Operating Parameter | Lifespan(hrs) | 100,000 | ||||
Operation Temperature(℃) | -10~40 | |||||
Storage Temperature(℃) | -20~50 | |||||
Operation Humidity(RH) | 10%~60% | |||||
Storage Humidity(RH) | 10%~65% | |||||
















Cultural and tourism commercial performance solutions, providing full-site stage design to help users enjoy uninterrupted high-definition live streaming.
Equipped with a complete set of professional audio and video processing systems for on-site stages, it features an original fully die-cast aluminum fully sealed box body. Combined with a unique quick-lock design and a fine-tuning mechanism for seams, it can easily and quickly achieve high-precision seamless splicing of the entire screen, with low brightness, high gray scale and high refresh rate, making the displayed picture more delicate, realistic and vivid.
The realistic visuals and stunning music are perfectly combined to create a dreamy stage effect, allowing the audience on site to fully immerse themselves in the lively atmosphere and participate in the star-studded audio-visual feast throughout, igniting your stage performance with creativity.
This solution is mainly applied to various high-quality rental performance venues such as indoor and outdoor stage backgrounds, concerts, large-scale events, conference forums, exhibition displays, stage performances, TV stations, wedding events, hotels, bars, KTVS, etc





Company Profile







Zhengzhou Shenglong Information Technology Co., Ltd. (stock code: 831361), founded in 1998, is one of the earliest high-tech enterprises in the world engaged in the design, production and installation of LED display systems. The company adheres to the concept of creative R&D design and is committed to the research and development of technical products in the field of special displays. It is an advocate and pioneer of new display technologies in China.
Zhengzhou Shenglong Information Technology Co., Ltd. has a technical team with doctoral supervisors, master supervisors and senior engineers as the core. The technical staff have decades of R&D experience. Many of them have participated in the compilation of the textbook "Optoelectronic Display Technology and Application" for Chinese universities. Team members have participated in the
construction of major projects such as the Chinese government's countdown board for the return of Hong Kong to the world-renowned Tiananmen Square, the largest screen in Asia, and the Sydney Olympics.
Zhengzhou Shenglong Information Technology Co., Ltd. has a technical team with doctoral supervisors, master supervisors and senior engineers as the core. The technical staff have decades of R&D experience. Many of them have participated in the compilation of the textbook "Optoelectronic Display Technology and Application" for Chinese universities. Team members have participated in the
construction of major projects such as the Chinese government's countdown board for the return of Hong Kong to the world-renowned Tiananmen Square, the largest screen in Asia, and the Sydney Olympics.

Zhengzhou Shenglong Information Technology Co., Ltd. has successively passed ISO quality system, national standard quality system, information security management system, intellectual property management system, as well as US FCC certification, EU CE, EU RoHS and other certifications;
It has more than 70 patents and software copyrights, and has established the "Henan Intelligent Control and Aviation Information Technology Engineering Technology Research Center" and "Zhengzhou Information Security Protection Display System Engineering Technology Research Center" scientific research platforms recognized by the government;
Won nearly 100 qualifications and honors such as "Specialized and New", "Top 50 Electronic Information Enterprises", "National 100 Quality and Integrity Enterprises", "National VR Industry Quality Leading Enterprise", "Science and Technology Innovation Award", and "Excellent Technology Award"

In 2003, Shenglong Co., Ltd. successfully developed a sub-outdoor display system, which reduced the cost of conventional outdoor display screens by more than half and quickly became popular throughout the country;
In 2010, the first domestic macro rear projection based on LED light source was successfully developed and patented, effectively solving the moiré problem caused by camera shooting of studio and stage background screens, and creating a new display technology field;
In 2013, a series of three-dimensional display products based on LED light source were successfully developed and patented, solving the problem of lack of 3D large-screen display equipment in domestic 3D teaching. It was listed as a recommended product for 3D classroom solutions in the "3D Education Research Blue Book" of the Ministry of Education, and has been widely used in many primary and secondary schools, colleges and universities, and research institutes across the country;
Based on the needs of confidentiality system customers, Shenglong Co., Ltd. took the lead in developing the "Information Security Display System" in 2020, filling the gap in the field of information security display in China.
Project Construction
Professional construction team, On-site installation service.












Customer Photos

Exhibition



Product Summary
ParameterSLED-ZN 5050 26/SSLED-ZN 5050 26/SSLED-ZN 5050 26/S Module ParameterPixel Pitch(mm)2.62.973.91LED TypeSMD1515SMD1515SMD2020Module Resolution(W*H)96*9684*8464*64Pixel Density(point/㎡)14745611289665536 Cabinet ParameterModule Composition(W*H)2*2=4PcsCabinet Resolution(W*H)192*192168*168128...
